Go from point cloud to mesh to surface to solid all in a single environment, with maximum efficiency
REcreate reverse engineering software is easily integrated into any existing production workflow. It’s designed to work with Hexagon systems, or a host of third-party systems and data sources, operating either as a full end-to-end reverse engineering solution, or to complement existing technologies.
Benefits And Features
A full range of reverse engineering applications
Full CAD capability
REcreate is at its core a full CAD system, enabling users to create 3D models. It can also be easily converted to 2D drawings that are ready to use throughout manufacturing as needed. With REcreate, you can also ‘fill in the gaps’ to produce complete and accurate 3D CAD models from fragmented data.
The digital thread
REcreate enables teams across design, production, and inspection to share a single, consistent thread of data. REcreate connects CAD and CAM in the virtual environment to Manufacturing and Metrology in the physical environment, seamlessly connecting the digital thread throughout the manufacturing process.
Optimizing use
REcreate is easily configurable, enabling each user’s experience and workflow to be shaped according to their preferences and specific needs.
Training and Resources
Take advantage of various learning opportunities
Visit the Catalog page for a complete list of educational content. You can enroll for training, complete self-paced courses, register for distance learning, classroom instruction, live training events, and download or print your completion certificate.
Dive into our documentation to explore the full potential of product offerings
Your ultimate resource for practical guidance and support. Here, you’ll find a wealth of step-by-step how-to guides, detailed tutorials, and handy tips and tricks. Whether you’re troubleshooting an issue or looking for ways to optimize your use of our products, our Documentation Center provides clear and concise information to help you get the most out of your experience.
Expand your knowledge
Our Knowledge Base, your go-to hub for in-depth insights and valuable information. Explore a rich collection of articles, thought-provoking posts, and detailed white papers crafted to provide you with the knowledge you need to excel. From industry trends to expert analyses, our Knowledge Base is designed to keep you informed and empowered with the latest and most relevant content.
Downloads are only available on the desktop version. Please access our site from a desktop to download.
Frequently Asked Questions
What are the system requirements for Recreate?
The system requirements for REcreate can be found here.
How do I control the visibility of the instructional prompts that appear on the screen?
Control of the prompts can be configured within the File > Settings > Options > User Interface 'Show command prompts in graphics area' as detailed here.
How do I change the step value for selecting triangles so that I can better control the selection?
Settings to control the step value for selecting triangles are found in File, Settings, Options, System, set ‘Dynamic triangles angular deviation’ to a smaller value as detailed here.
How do I reset my DESIGNER/REcreate settings back to the default "As installed"?
Go to File > Settings and click on Restore default settings. You will need to restart the application for the changes to take effect. This should restore all changes made in the DESIGNER/REcreate configuration. Refer to the image here.
How do I repair an extracted surface use Mesh to surface-command?
Use the edit surface-command in wireframe mode to select the damaged surface and repair with natural limits in U/V as detailed here.
Support
Connect and collaborate with your peers and experts
Nexus Community provides you with excellent peer forums and the opportunity to learn from thousands of others in your industry. Currently, there are 25 products active and 80+ peer forums waiting for you to dive into. Discover best practices, and get answers you need to succeed. Once you register for Nexus, you can access the community forums.
